Output mothod
输出模式
|
PNP N.O./N.C.
NPN N.O./N.C.
|
KC3030-KP2
|
KC3030-KP2K
|
|
Description / 外型
|
Standard / 标准M30
|
|
Standard sensing object / 标准检测物
|
Conductor or electric - medium / 导体电中性
|
|
Sensing distance / 检出距离
|
2~30 mm
|
|
Hysteresis / 迟滞
|
≦ 10 % of sensing distance
|
|
Response time / 反应时间
|
100 ms Max.
|
|
Operating voltage / 工作电压
|
DC12 ~ 24 V
|
|
Current consumption / 消耗电流
|
≦ 8 mA no-load
|
|
Load current / 负载电流
|
100 mA Max at DC 24V
|
|
Leakage current / 漏电流
|
≦ 1.1 mA no-load
|
|
Residual voltage / 残余电压
|
≦ DC 1.5V
|
|
Insulation resistance / 隔离阻抗
|
20M Ω min. (DC500V)
|
|
Voltage withstandability / 绝缘耐压
|
AC1000V 60Hz for 60 Sec.
|
|
Operating temperature / 工作温度范围
|
-20℃ ~ + 60℃
|
|
Protection degree / 防水等级
|
IP 66
|
|
Wiring method / 出线方式
|
Pre-wire Ø5.2 x 2M / 4-wires
|
M12 pigtailed type / M12接头15cm电线式
|
|
Weight / 重量
|
Approx. 135g
|
Approx. 80g
|
