Crosstalk prevention. /相互干擾
When two sensors are mounted in parallel or face to face, keep the minimum distance (according to the table below) to avoid crosstalk.

Sensing surface	Model	B (mm)	C (mm)
Shielded /隔離型	SC0801	≧20	≧15
	SC1202	≧30	≧20
	SC1805	≧50	≧35
	SC3010	≧100	≧70
Unshielded /非隔離型	SC0802	≧80	≧60
	SC1204	≧120	≧100
	SC1808	≧200	≧110
	SC3015	≧300	≧200
	SCP3015	≧300	≧200

? Influenced by surrounding metals. /周圍金屬影響
The surrounding metals will influence the sensing performance. Please keep the minimum sensing distance according to the table below.

Shielded / 隔離型

Model	D (mm)	E (mm)	F (mm)	G (mm)
SC0801	≧12	≧1	≧0	≧1
SC1202	≧18	≧2	≧0	≧2
SC1805	≧27	≧5	≧0	≧5
SC3010	≧45	≧10	≧0	≧10

Unshielded / 非隔離型

Model	H (mm)	I(mm)	J(mm)	K (mm)	L (mm)
SC0802	≧22	≧8	≧6	≧22	≧6
SC1204	≧36	≧20	≧15	≧44	≧15
SC1808	≧54	≧40	≧22	≧55	≧22
SC3015	≧90	≧70	≧30	≧90	≧30
SCP3015	≧90	≧70	≧30	≧90	≧30

? 接線圖

DC TYPE
SC□-N□	SC□-N2□	SC□-P□	SC□-P2□

SC□-KP2□

AC TYPE
SC□-A□	SC□-A2□

Ø4/M5规格

Output mothod 输出模式	NPN N.O.	SC0401-N	SC0501-N
	NPN N.C.	–	–
	PNP N.O.	SC0401-P	SC0501-P
	PNP N.C.	–	–
	NPN N.O./N.C. PNP N.O./N.C.	–	–
	SCR N.O.	–	–
	SCR N.C.	–	–
Sensing surface / 检测方向		Shielded / 隔离型
Description / 外型		Standard / 标准O4	Standard / 标准M5
Standard sensing object / 标准检测物		Iron 4 x 4 x 1mm	Iron 5 x 5 x1mm
Sensing distance / 检出距离		0.8 mm
Secure sensing distance / 建议距离		0 to 0.5 mm
Hysteresis / 迟滞		≦ 10 % of sensing distance
Response time / 反应时间		0.2 ms Max.
Operating voltage / 工作电压		DC10 ~ 30 V
Current consumption / 消耗电流		≦ 10 mA no-load
Load current / 负载电流		200 mA Max
Leakage current / 漏电流		≦ 0.1 mA no-load
Residual voltage / 残余电压		≦ DC 2V 200mA
Voltage withstandability / 绝缘耐压		AC1000V 60Hz for 60 Sec.
Operating temperature / 工作温度范围		-25℃ ~ + 70℃
Protection degree / 防水等级		IP 67
Wiring method / 出线方式		Ø3.5 x 2M x 3 wires
Weight / 重量		Approx. 26g	Approx. 26g

M8規格

Output mothod 输出模式	NPN N.O.	SC□0801-N	SC□0801-ND	SC□0802-N	SC□0802-ND
	NPN N.C.	SC□0801-N2	SC□0801-N2D	SC□0802-N2	SC□0802-N2D
	PNP N.O.	SC□0801-P	SC□0801-PD	SC□0802-P	SC□0802-PD
	PNP N.C.	SC□0801-P2	SC□0801-P2D	SC□0802-P2	SC□0802-P2D
	NPN N.O./N.C. PNP N.O./N.C.	–	–	–	–
	SCR N.O.	–	–	–	–
	SCR N.C.	–	–	–	–
Sensing surface / 检测方向		Shielded / 隔离型		Unshielded / 非隔离型
Description / 外型		Standard / 标准M8
Standard sensing object / 标准检测物		Iron 8 × 8 × 1 mm
Sensing distance / 检出距离		1 mm		2 mm
Secure sensing distance / 建议距离		0 to 0.8 mm		0 to 1.6 mm
Hysteresis / 迟滞		≦ 10 % of sensing distance
Response time / 反应时间		1 ms Max.
Operating voltage / 工作电压		DC12 ~ 24 V
Current consumption / 消耗电流		≦ 8 mA no-load
Load current / 负载电流		100 mA Max
Leakage current / 漏电流		≦ 1.1 mA no-load
Residual voltage / 残余电压		≦ DC 1.5V
Insulation resistance / 隔离阻抗		20MΩ min. (DC500V)
Voltage withstandability / 绝缘耐压		AC1000V 60Hz for 60 Sec.
Operating temperature / 工作温度范围		-20℃ ~ + 60℃
Protection degree / 防水等级		IP 66
Wiring method / 出线方式		Pre-wired Ø3 x 2M / 3-wires	M8 pigtailed type / M8接头15cm电线式	Pre-wired Ø3 x 2M / 3-wires	M8 pigtailed type / M8接头15cm电线式
Weight / 重量		Approx. 30g	Approx. 12g	Approx. 30g	Approx. 12g

M12埋入式規格

Output mothod 输出模式	NPN N.O.	SC□1202-N	SC□1202-ND	SC□1202-ND1
	NPN N.C.	SC□1202-N2	SC□1202-N2D	SC□1202-N2D1
	PNP N.O.	SC□1202-P	SC□1202-PD	SC□1202-PD1
	PNP N.C.	SC□1202-P2	SC□1202-P2D	SC□1202-P2D1
	NPN N.O./N.C. PNP N.O./N.C.	SC1202-KP2	–	–
	SCR N.O.	SC1202-A	–	–
	SCR N.C.	SC1202-A2	–	–
Sensing surface / 检测方向		Shielded / 隔离型
Description / 外型		Standard / 标准M12
Standard sensing object / 标准检测物		Iron 12 x 12 x 1 mm
Sensing distance / 检出距离		2 mm
Secure sensing distance / 建议距离		0 to 1.6 mm
Hysteresis / 迟滞		≦ 10 % of sensing distance
Response time / 反应时间		DC Type 1 ms Max. or AC Type 50ms
Operating voltage / 工作电压		DC 12 ~ 24V or AC90 ~ 260 V
Current consumption / 消耗电流		DC : ≦ 8 mA no-load or AC : 2 mA Max
Load current / 负载电流		DC : 100 mA Max at DC 24V or AC : 5 ~ 300 mA Max
Leakage current / 漏电流		≦ 1.1 mA no-load
Residual voltage / 残余电压		≦ DC 1.5V
Insulation resistance / 隔离阻抗		20MΩ min. (DC500V)
Voltage withstandability / 绝缘耐压		AC1000V 60Hz for 60 Sec.
Operating temperature / 工作温度范围		-20℃ ~ + 60℃
Protection degree / 防水等级		IP 66
Wiring method / 出线方式		N/P : Ø4.2x 2M / 3-wires KP2 :Ø4.2x2M / 4-wires AC :Ø4.2x2M / 2-wires	M8 pigtailed type / M8 接头15cm电线式	M12 plug-in connector type / M12 接头
Weight / 重量	SC	Approx. 65g	Approx. 15g	Approx. 20g
	SCL	Approx. 70g	Approx. 20g	Approx. 25g
	SCS	Approx. 60g	Approx. 15g	Approx. 20g

M12露出式規格

Output mothod 输出模式	NPN N.O.	SC□1204-N	SC□1204-ND	SC□1204-ND1
	NPN N.C.	SC□1204-N2	SC□1204-N2D	SC□1204-N2D1
	PNP N.O.	SC□1204-P	SC□1204-PD	SC□1204-PD1
	PNP N.C.	SC□1204-P2	SC□1204-P2D	SC□1204-P2D1
	NPN N.O./N.C. PNP N.O./N.C.	SC1204-KP2	–	–
	SCR N.O.	SC1204-A	–	–
	SCR N.C.	SC1204-A2	–	–
Sensing surface / 检测方向		Unshielded / 非隔离型
Description / 外型		Standard / 标准M12
Standard sensing object / 标准检测物		Iron 12 x 12 x 1 mm
Sensing distance / 检出距离		4 mm
Secure sensing distance / 建议距离		0 to 3.2 mm
Hysteresis / 迟滞		≦ 10 % of sensing distance
Response time / 反应时间		DC Type 2 ms Max. or AC Type 50ms
Operating voltage / 工作电压		DC 12 ~ 24V or AC90 ~ 260 V
Current consumption / 消耗电流		DC : ≦ 8 mA no-load or AC : 2 mA Max
Load current / 负载电流		DC : 100 mA Max at DC 24V or AC : 5 ~ 300 mA Max
Leakage current / 漏电流		≦ 1.1 mA no-load
Residual voltage / 残余电压		≦ DC 1.5V
Insulation resistance / 隔离阻抗		20MΩ min. (DC500V)
Voltage withstandability / 绝缘耐压		AC1000V 60Hz for 60 Sec.
Operating temperature / 工作温度范围		-20℃ ~ + 60℃
Protection degree / 防水等级		IP 66
Wiring method / 出线方式		N/P : Ø4.2x 2M / 3-wires KP2 :Ø4.2x2M / 4-wires AC :Ø4.2x2M / 2-wires	M8 pigtailed type / M8 接头15cm电线式	M12 plug-in connector type / M12 接头
Weight / 重量	SC	Approx. 65g	Approx. 15g	Approx. 20g
	SCL	Approx. 70g	Approx. 20g	Approx. 25g
	SCS	Approx. 60g	Approx. 15g	Approx. 20g

M18埋入式規格

Output mothod 输出模式	NPN N.O.	SC□1805-N	SC□1805-ND	SC□1805-ND1
	NPN N.C.	SC□1805-N2	SC□1805-N2D	SC□1805-N2D1
	PNP N.O.	SC□1805-P	SC□1805-PD	SC□1805-PD1
	PNP N.C.	SC□1805-P2	SC□1805-P2D	SC□1805-P2D1
	NPN N.O./N.C. PNP N.O./N.C.	SC1805-KP2	SC1805-KP2K	–
	SCR N.O.	SC1805-A	SC1805-AK	–
	SCR N.C.	S1C805-A2	SC1805-A2K	–
Sensing surface / 检测方向		Shielded / 隔离型
Description / 外型		Standard / 标准M18
Standard sensing object / 标准检测物		Iron 18 x 18 x 1 mm
Sensing distance / 检出距离		5 mm
Secure sensing distance / 建议距离		0 to 4 mm
Hysteresis / 迟滞		≦ 10 % of sensing distance
Response time / 反应时间		DC Type 2 ms Max. or AC Type 50ms
Operating voltage / 工作电压		DC 12 ~ 24V or AC90 ~ 260 V
Current consumption / 消耗电流		DC : ≦ 8 mA no-load or AC : 2 mA Max
Load current / 负载电流		DC : 100 mA Max at DC 24V or AC : 5 ~ 300 mA Max
Leakage current / 漏电流		≦ 1.1 mA no-load
Residual voltage / 残余电压		≦ DC 1.5V
Insulation resistance / 隔离阻抗		20MΩ min. (DC500V)
Voltage withstandability / 绝缘耐压		AC1000V 60Hz for 60 Sec.
Operating temperature / 工作温度范围		-20℃ ~ + 60℃
Protection degree / 防水等级		IP 66
Wiring method / 出线方式		N/P : Ø5.2x 2M / 3-wires KP2 :Ø5.2x2M / 4-wires AC :Ø5.2x2M / 2-wires	M12 pigtailed type / M12 接头15cm 电线式	M12 plug-in connector type / M12 接头
Weight / 重量	SC	Approx. 96g	Approx. 35g	K1:Approx.30g M1:Approx. 35g
	SCL	Approx. 116g	Approx. 55g	K1:Approx.50g M1:Approx. 55g

M18露出式規格

Output mothod 输出模式	NPN N.O.	SC□1808-N	SC□1808-ND	SC□1808-ND1
	NPN N.C.	SC□1808-N2	SC□1808-N2D	SC□1808-N2D1
	PNP N.O.	SC□1808-P	SC□1808-PD	SC□1808-PD1
	PNP N.C.	SC□1808-P2	SC□1808-P2D	SC□1808-P2D1
	NPN N.O./N.C. PNP N.O./N.C.	SC1808-KP2	SC1808-KP2K	–
	SCR N.O.	SC1808-A	SC1808-AK	–
	SCR N.C.	SC1808-A2	SC1808-A2K	–
Sensing surface / 检测方向		Unshielded / 非隔离型
Description / 外型		Standard / 标准M18
Standard sensing object / 标准检测物		Iron 18 x 18 x 1 mm
Sensing distance / 检出距离		8 mm
Secure sensing distance / 建议距离		0 to 6.4 mm
Hysteresis / 迟滞		≦ 10 % of sensing distance
Response time / 反应时间		DC Type 2 ms Max. or AC Type 50ms
Operating voltage / 工作电压		DC 12 ~ 24V or AC90 ~ 260 V
Current consumption / 消耗电流		DC : ≦ 8 mA no-load or AC : 2 mA Max
Load current / 负载电流		DC : 100 mA Max at DC 24V or AC : 5 ~ 300 mA Max
Leakage current / 漏电流		≦ 1.1 mA no-load
Residual voltage / 残余电压		≦ DC 1.5V
Insulation resistance / 隔离阻抗		20MΩ min. (DC500V)
Voltage withstandability / 绝缘耐压		AC1000V 60Hz for 60 Sec.
Operating temperature / 工作温度范围		-20℃ ~ + 60℃
Protection degree / 防水等级		IP 66
Wiring method / 出线方式		N/P : Ø5.2x 2M / 3-wires KP2 :Ø5.2x2M / 4-wires AC :Ø5.2x2M / 2-wires	M12 pigtailed type / M12 接头15cm 电线式	M12 plug-in connector type / M12 接头
Weight / 重量	SC	Approx. 90g	Approx. 30g	K1:Approx.25g M1:Approx. 30g
	SCL	Approx. 115g	Approx. 55g	K1:Approx.50g M1:Approx. 55g

M30埋入式規格

Output mothod 输出模式	NPN N.O.	SC□3010-N	SC□3010-NK	SC□3010-NK1
	NPN N.C.	SC□3010-N2	SC□3010-N2K	SC□3010-N2K1
	PNP N.O.	SC□3010-P	SC□3010-PK	SC□3010-PK1
	PNP N.C.	SC□3010-P2	SC□3010-P2K	SC□3010-P2K1
	NPN N.O./N.C. PNP N.O./N.C.	SC3010-KP2	SC3010-KP2K	–
	SCR N.O.	SC3010-A	SC3010-AK	–
	SCR N.C.	SC3010-A2	SC3010-A2K	–
Sensing surface / 检测方向		Shielded / 隔离型
Description / 外型		Standard / 标准M30
Standard sensing object / 标准检测物		Iron 30 x 30 x 1 mm
Sensing distance / 检出距离		10 mm
Secure sensing distance / 建议距离		0 to 8 mm
Hysteresis / 迟滞		≦ 10 % of sensing distance
Response time / 反应时间		DC Type 3.3 ms Max. or AC Type 50ms
Operating voltage / 工作电压		DC 12 ~ 24V or AC90 ~ 260 V
Current consumption / 消耗电流		DC : ≦ 8 mA no-load or AC : 2 mA Max
Load current / 负载电流		DC : 100 mA Max at DC 24V or AC : 5 ~ 300 mA Max
Leakage current / 漏电流		≦ 1.1 mA no-load
Residual voltage / 残余电压		≦ DC 1.5V
Insulation resistance / 隔离阻抗		20MΩ min. (DC500V)
Voltage withstandability / 绝缘耐压		AC1000V 60Hz for 60 Sec.
Operating temperature / 工作温度范围		-20℃ ~ + 60℃
Protection degree / 防水等级		IP 66
Wiring method / 出线方式		N/P : Ø5.2x 2M / 3-wires KP2 :Ø5.2x2M / 4-wires AC :Ø5.2x2M / 2-wires	M12 pigtailed type / M12 接头15cm 电线式	M12 plug-in connector type / M12 接头
Weight / 重量	SC	Approx. 145g	Approx. 90g	K1:Approx.80g M1:Approx. 100g
	SCL	Approx. 165g	Approx. 110g	K1:Approx.100g M1:Approx. 120g

M30露出式規格

Output mothod 输出模式	NPN N.O.	SC□3015-N	SC□3015-NK	SC□3015-NK1
	NPN N.C.	SC□3015-N2	SC□3015-N2K	SC□3015-N2K1
	PNP N.O.	SC□3015-P	SC□3015-PK	SC□3015-PK1
	PNP N.C.	SC□3015-P2	SC□3015-P2K	SC□3015-P2K1
	NPN N.O./N.C. PNP N.O./N.C.	SC3015-KP2	SC3015-KP2K	–
	SCR N.O.	SC3015-A	SC3015-AK	–
	SCR N.C.	SC3015-A2	SC3015-A2K	–
Sensing surface / 检测方向		Unshielded / 非隔离型
Description / 外型		Standard / 标准M30
Standard sensing object / 标准检测物		Iron 30 x 30 x 1 mm
Sensing distance / 检出距离		15 mm
Secure sensing distance / 建议距离		0 to 12 mm
Hysteresis / 迟滞		≦ 10 % of sensing distance
Response time / 反应时间		DC Type 3.3 ms Max. or AC Type 50ms
Operating voltage / 工作电压		DC 12 ~ 24V or AC90 ~ 260 V
Current consumption / 消耗电流		DC : ≦ 8 mA no-load or AC : 2 mA Max
Load current / 负载电流		DC : 100 mA Max at DC 24V or AC : 5 ~ 300 mA Max
Leakage current / 漏电流		≦ 1.1 mA no-load
Residual voltage / 残余电压		≦ DC 1.5V
Insulation resistance / 隔离阻抗		20MΩ min. (DC500V)
Voltage withstandability / 绝缘耐压		AC1000V 60Hz for 60 Sec.
Operating temperature / 工作温度范围		-20℃ ~ + 60℃
Protection degree / 防水等级		IP 66
Wiring method / 出线方式		N/P : Ø5.2x 2M / 3-wires KP2 :Ø5.2x2M / 4-wires AC :Ø5.2x2M / 2-wires	M12 pigtailed type / M12 接头15cm 电线式	M12 plug-in connector type / M12 接头
Weight / 重量	SC	Approx. 135g	Approx. 80g	K1:Approx.70g M1:Approx. 90g
	SCL	Approx. 170g	Approx. 115g	K1:Approx.105g M1:Approx. 125g
